10mm RGB 4 DMX512 LED Strobe Light Bar 60 Hz 2A 20W Emergency Strobe Lights

Product Categories

Guangzhou Xinyu Stage Lighting Installation Factory

Contact Now

10mm RGB 4 DMX512 LED Strobe Light Bar 60 Hz 2A 20W Emergency Strobe Lights

Brand Name : Diy

Model Number : VS-40

Certification : CE&RoHS

Place of Origin : Guangzhou , China

MOQ : 12 pcs, 1pcs sample is avilable

Price : Negoticated

Payment Terms : T/T, D/P, Western Union

Supply Ability : 1000 pcs monthly

Delivery Time : 3-7 days for sample and 20 days for big order

Packaging Details : Color box / Carton

Voltage : AC110-220V, 50-60Hz

Power : 20 W

Light source : 198*10mm RGB LED

Play mode : Auto, Sound active,Master/Slave Control

Effecting : Promise blending colors, change colors and strobe

Work environment : -10 to -35 degrees

Contact Now

198pcs 10mm RGB LED Strobe Ligh,Led DMX light,disco strobe light

Parameters

Voltage: AC110V 60 Hz
Current: 2A
Power: 20W
led quantity: 198pcs high brightness lamps with 10 mm
Control: 4 DMX512 control channels
Operating mode: dmx512 / master / slave / stand-alone, strobe, change color
5,52x23x21 (1pcs / CTN)
6. packin size: 72x55x45 cm (6pcs / CTN)

2, DMX512 control channels:
Channel 1 dimming / Strobe
Channel 2, red
Channel 3 Green
Channel 4, blue

3, Function of choice for stand-alone mode
DIP 1.2, 3 / ON: the red light;
DIP 4.5, 6 / ON: the green light;
DIP 7.8 / ON: light blue;
DIP 1.9 / ON: RGB high brightness LED;
DIP 7.8, 9 / ON: RGB color Hopping
DIP 1.9 / ON: RGB color Hopping fast and slow

4, Master / Slave
To set a master in a control channel, stand-alone with the master (the above dive mode in stand-alone mode)
All other set to be a slave, to all DIP 1/10 and on / on.
Attention: a channel can only set a master.

Applications : It is suitable for regulating mood, apply for different occasions family gatherings to sing karaoke OK, dance halls, nightclubs, discos, bars, KTV bars, shopping malls, squares, parks and other uses.

Pictures

Accessories

LED Light...............1pcs

Power Cable............1pcs

Signal cable..............1pcs

User Manual..........................1pcs
